Congestion

Congestion makes the design non-routable that means routing will not be converged if there are congestion in the design. Let's know about congestion in details.

Swasti PujariAssociate Director, Backend Engineering
Published
Updated
Read time
1 min
  • Physical Design
  • Placement
On this page 4 sections
  1. What is Congestion?
  2. Types of Congestion
  3. Reasons for Congestion
  4. Fixes for Congestion

What is Congestion?#

If the number of required routing resources exceeds the available routing tracks, the area becomes congested. High congestion leads to detours and poorer results. Severe congestion can make the design non-routable, meaning routing will not converge if congestion persists.

Types of Congestion#

There are basically two types of congestion:

  • Placement congestion
  • Routing congestion.

    We need to avoid both the types of congestion in our design.

    Reasons for Congestion#

    • There are different reasons for the congestion which are as follows:
      • Bad Floorplan.
      • High standard cell density in particular area.
      • High pin density in particular area.
      • Missing/Small Halos near macro cell.
      • Huge number of cells sitting near the macro cell.

    Fixes for Congestion#

    • There are below ways to fix congestion issues in design:
      • Use blockages in the design, partial blockages help more in optimized way.
      • Cell padding
      • Module padding
      • Decomposition of large cells into small cells (Pin distribution happens).
